EATON 9E EXTENDED BATTERY MODULE (EBM) – 9EEBM72
Product Overview
The Eaton 9EEBM72 is a 72 V extended battery module (EBM) engineered to increase the runtime of Eaton 9E UPS systems. It seamlessly attaches to compatible UPS units, delivering prolonged backup power to critical loads during extended outages.
Key Features
- Provides additional energy capacity for extended backup times
- Hot-swappable design allows battery replacement without shutting down connected equipment
- Sealed, maintenance-free lead-acid batteries for reliable performance
- Integrated safety circuitry for overcharge, over-discharge, and thermal protection
- Dedicated power cable ensures secure, error-free connection to the UPS
Technical Specifications
| Specification | Details |
|---|---|
| Module Voltage | 72 V |
| Battery Type | Sealed, valve-regulated lead-acid |
| Battery Quantity | 12 |
| Individual Battery Rating | 12 V / 9 Ah |
| Dimensions (D × W × H) | 19 cm × 39.9 cm × 33 cm |
| Weight | 35.8 kg |
| Connectivity | Supplied EBM power cable |
| Compliance | IEC/EN 62040-1, IEC/EN 62040-2, CE Mark, EAC, TUV |
| Warranty | 2 years limited |
Compatibility & Installation
The 9EEBM72 is validated for use with Eaton 9E UPS models, including the 9E2000I and 9E3000I. Installation involves connecting the module to the UPS via the included power cable and configuring the UPS settings to recognize the additional battery pack.
Package Contents
- Extended Battery Module (EBM) 9EEBM72
- EBM power cable
- Quickstart guide
Warranty & Support
Eaton provides a two-year limited warranty covering defects in materials and workmanship. Comprehensive technical support, replacement services, and the latest documentation are available through Eaton’s global support channels.
